Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8

Place of Origin : Guangdong, China

Model Number : VA series

Brand Name : Longvision

Packaging Details : wooden/carton case

Supply Ability : 3000 Square Meter/Square Meters per Month

MOQ : 1 Square Meter

Price : $499.00 - $999.00/Square Meter

Certification : CE FCC UL ROHS CCC

Payment Terms : D/P, T/T, Western Union, MoneyGram

Delivery Time : 4-8 Days

Panel Size : 640mm*480mm

Material : Die-casting aluminum

Module size : 320mm*160mm

Brightness : 700-1000nits

LED type : SMD1515 (3in1)/ 1212

Refresh rate : 3840-7680Hz

Weight : 7kg

Input voltage : AC110V - AC240V

Lifespan : 100 000 Hours

Contact Now

Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8

Advantages
1. High Precision: all-in-one design with die-casting aluminum fashioning technology
2. 100% Front Maintenance:all components dismount from front side, fast and easy
3. Wireless Connection: adopt hard-wired connector, support hot plug to dismounting easily
4. Fast Heat Dissipation: multi-point heat emission holes speed up efficiency of heat dissipation

Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8

Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Lightweight Fine Pitch Led Display Video Wall Pixel P1.2 P1.5 P1.8
Specifications
Model
VA 1.2
VA 1.5
VA 1.6
VA 1.8
VA 1.8
Pixel Pitch
1.25
1.53
1.667
1.83
1.86
Application
UHD Display
Pixel Density
640000 dots/m²
427186 dots/m²
360000 dots/m²
298605 dots/m²
289050
dots/m²
LED Type
SMD1010
SMD1212
SMD1212
SMD1515
SMD1515
Brightness
＞700cd/m²
＞700cd/m²
＞700cd/m²
＞700cd/m²
＞700cd/m²
Module Size
320*160 mm
320*160 mm
320*160 mm
320*160 mm
320*160 mm
Module Resolution
256*128
208*104
192*96
174*87
172*86
Cabinet Size
640*480 mm
640*480 mm
640*480 mm
640*480 mm
640*480 mm
Cabinet Resolution
512*384
416*312
384*288
348*261
344*258
Cabinet Material
Die-casting Aluminum
Cabinet Weight
7kg/cbn
Viewing Angle
H:160° / V:140°
Refresh Rate
≥3840Hz
Viewing Distance
1.2m~15m
1.5m~20m
1.6m~25m
1.8m~30m
1.8m~30m
Gray Scale
14~16bit
Max Power Consumption
700W/m²
700W/m²
800W/m²
800W/m²
800W/m²
Avg. Power Consumption
350W/m²
350W/m²
400W/m²
400W/m²
400W/m²
Power Input
AC 100～240V
Frequency
50～60Hz
Maintenance
100% Front Service
Operating Temperature
-20℃～50℃
Operating Humidity
10%～95%
Lifetime
100,000H

FAQ:
Q1. What about LED Display MOQ?
A1. Any quantity is acceptable for your order. And the price is negotiable for large quantity.

Q2. What about Longvision capacity?
A2.3000sqm per month.
8 modernized dust-free and static-free production lines,
6 new YAMAHA and PANASONIC high speed SMT machines,
2 large leadless reflow oven
250 skilled workers.

Q3. When will you make the delivery?
A3. 3-5 working days when we have LED module stock
10-15 days for the new production led finished screen according to the size and quantities of your order.

Q4. How about the warranty time?
A4. Our standard is 2 years.
But you are willing to pay extra money for after sales and adopt industry top quality material,we can accept 3-5 years warranty.

Q5. Do you provide any free spare parts in each order?
A5. Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED
lamp, IC, mask, power supply, receiving card, etc.

Q6. What`s trade terms you accept?
A6. We accept EXW,CIF,CNF,DDP,DDU etc
